EG4®LiFePower4 48V v2 100Ah Lithium Iron Phosphate Battery

The EG4 LiFePower4 48V v2 battery retains the robust performance of the original model, now with enhanced features for improved user experience and system integration. Built with 16 UL-recognized 3.2V LiFePO4 cells, this battery provides >6,000 cycles at 80% Depth of Discharge (DoD), a nominal voltage of 51.2V, and a 5.12kWh capacity. Its 100A Battery Management System (BMS) supports parallel connections of up to 64 units, making it adaptable for larger systems.

RS485 and CAN bus compatibility with a six position DIP switch ensures accurate settings of protocols and easy integration with various inverters. The LiFePower4 48V v2 also includes Emergency Stop (E-Stop) and dual fire arrestors for added safety. This battery is backed by a 10-year limited warranty.

Description

FEATURES & BENEFITS:

Built On a Proven Foundation:
Retains robust architecture and high performance of its predecessor.

Convenient Control:
Equipped with a BMS communication on/off switch

Customizable Integration:
New six position DIP switch allows convenient inverter and battery configuration

Streamlined Connectivity:
Additional terminal connections with two positive and two negative terminals

Broad Inverter Compatibility:
CAN bus and RS485 ports enable communication with a wider range of inverters

Built-In Safety Feature:
E-Stop (Emergency Stop) rapid shutdown functionality for secure operation in high-risk settings

Enhanced Safety:
Dual on-board fire arrestors for added peace of mind

KEY SPECIFICATIONS:

Nominal Voltage: 51.2V
Energy Capacity: 5.12kWh
Charge Capacity: 100Ah
BMS: Internal 100A Battery Management System
Certified Cells: 16 UL-recognized 3.2V cells in series.
Closed-Loop Support Up to 64 batteries
Total Capacity: 327.7kWh
Safety Certified: UL 1973, UL 9540A, and UL 9540 Listed with 18kPV-12LV.
Design Life: Tested for >6,000 deep discharge cycles at 80% Depth of Discharge (DoD)
Dimensions: 6.1×19×17.4 in (155×442×470mm)
Weight: 99.6 lbs. (45.2kg)
Warranty: 10 year

California Proposition 65 Warning
